| Аудио/ Видео вход |
| Видео вход |
5 каналов |
| Аудио вход |
1 вход, 3.5mm |
| Сеть |
| Incoming Bandwidth |
40Mbps |
| Outgoing Bandwidth |
40Mbps |
| Mobile Software |
P2P/IP for IOS&Android (App Name: Easylive) |
| Internet Protocol |
TCP/UDP/HTTP/MULTICAST/UPnP/DHCP/DDNS/NTP/RTSP/SADP Etc |
| Email |
N/A |
| ANR |
Y |
| Remote Connection |
64 |
| Browser |
Support all browsers, including IE, Safari, Chrome, Edge.
(H.265 only supports configuration in non-IE kernel browsers) |
| Advanced |
Remaining Bandwidth Display |
| Video/Audio Output |
| HDMI Output |
1-ch, Resolution 1920×1080?1280×720?1440×900, 1366×768, 1280×800?1024×768?800×600 |
| VGA Output |
1-ch, Resolution 1920×1080?1280×720?1440×900, 1366×768, 1280×800?1024×768?800×600
Adjustable Output mode, Self-adaptive Resolution |
| Audio Output |
1-ch, RCA (Linear, 1kΩ) |
| Recording Resolution |
5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback |
2-ch 1080P/4-ch 720P |
| Display Split |
1/3/4/6 |
| Decoding |
| Compression |
S+265/H.265/H.264H/H.264M/H.264B |
| Preview Capability |
2-ch 1080P/4-ch 720P |
| E-Zoom |
Y |
| Hard Disk |
| SATA |
1 SATA for 1 HDD |
| eSATA |
N/A |
| Capacity |
Up to 10TB Capacity for Each HDD?0~45?? |
| NTFS Files System |
N/A |
| HDD Management |
Group and Quota, Customized Recording Days |
| RAID |
| RAID Mode |
N/A |
| RAID Management |
N/A |
| External Interface |
| HDMI Output |
1ch |
| VGA Output |
1ch |
| POE |
4 Independent 100 Mbps PoE Network Interfaces
45W(50W Optional), Max to 30W for Each Port |
| Network Interface |
1 RJ-45 10/100 Self-adaptive Ethernet Interfaces |
| Serial Interface |
N/A |
| USB Interface |
2 x USB2.0 |
| Alarm In/Out |
0/1 |
| Advance |
| Video Analytics(VCA) |
Camera VCA Function, including Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Loitering/Running/Parking/Face Detection/Crowd/On duty Detection/Video Abnormal Detection/Audio Abnormal Detection/Video defocus diagnosis/Video scene transformation diagnosis |
| I-Frame Record |
Y |
| Plug and Play |
Y, Only for Tiandy Cameras |
| Image Flip |
Y, Only for Tiandy Cameras |
| Corridor Mode |
Y, Only for Tiandy Cameras |
| Smart Search |
Quickly Search Target VCA Videos , Only for Tiandy Cameras |
| Trigger Recording |
Manual/Timing/Motion Detection/Port Alarm/ VCA Alarm/Video Lost |
| Smart Recording |
Set Recording Bit Rate for Different Time |
| Alarm Recording |
Pre Alarm Default 10s ( 5/10/15/60s Optional) , Post Alarm Default 10s (10/15/30/60/600s Optional ). |
| One Key Control |
Recording,one key add |
| Records Format |
SDV, MP4 |
| Records Encryption |
Y |
| Records Tag |
Y |
| Onvif |
Onvif(Profile S) |
| General |
| Language |
English,Spanish,Korean,Italian,Turkish,Thai,Russian,Polish,French,Traditional Chinese,Simplified Chinese?Dutch, Hebrew?UI? |
| Power Supply |
DC48V |
| Consumption(without HDD) |
≤20W(Hard Disk is not included) |
| Working Temperature |
-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Working Humidity |
10 % ~ 90 % |
| Chassis |
1U |
| Dimensions |
255mmx231mmx44mm |
| Weight |
≤4KG (without HDD) |
