| Камера |
| Матрица |
1/3" CMOS |
| Процессор |
ARM7 Architecture |
| Операционная система |
Embedded Linux |
| Min. чувствительность |
Color: 0.05Lux(F1.2,AGC ON) |
| B/W: 0.01Lux(F1.2,AGC ON); 0Lux with IR |
| Shutter Time |
1s?1/100000s |
| Объектив |
4mm, Angle of View: 82.7° |
| Крепление объектива |
φ12 |
| Auto Iris |
N/A |
| День/Ночь |
IR Cut Filter with Auto Switch |
| Wide Dynamic Range (WDR) |
120 dB |
| Digital Noise Reduction |
3D DNR |
| Формат компрессии |
| Формат видеосжатия |
H.265/H.264 HP/MP/BP/M-JPEG |
| Encode Type |
High Profile/Main Profile/Base Line Profile |
| Видео Bit Rate |
32Kbps~16Mbps |
| Аудио сжатие |
G.711A/G.711U/ADPCM/AAC |
| Аудио Bit Rate |
G711 8KHz, 64kbps
ADPCM 8KHz, 32kbps
AAC 48KHz, 96-320kbps |
| Изображение |
| Max. Image Resolution |
1440P(2560×1440)@25fps |
| Frame Rate |
PAL?1440P@25fps,QXGA@25fps |
| NTSC?1440P@25fps,QXGA@30fps |
| Triple Stream |
Mainstream: 1440P(2560×1440) |
| Substream: D1(704×576) |
| 3rd Stream: CIF(352×288) |
| Image Settings |
Brightness, Saturation, Contrast Adjustable by Client Software or Web Browser |
| HLC |
Да |
| Smart Defog |
Да |
| Corridor Format |
Да |
| EIS |
Да |
| ROI |
4 Zones |
| Privacy Mask |
4 Zones |
| Picture Overlay |
200 × 200, BMP 24bit, Zone Configurable |
| OSD |
16×16, 32×32, 24×24, 48×48, 64×64, 96×96 Size Letters Such as Week, Date, Time, Total 5 Regions |
| Network |
| Browser |
IE,Chrome,Firefox, Safari, Plug-in Free |
| Network Storage |
FTP |
| NTP |
Y |
| ANR |
Y, Auto store video in SD card when NVR disconnected, and upload video to NVR when resumed connection(Only Support Tiandy ANR NVR) |
| Video Analytics |
Tripwire/Double Tripwire/Perimeter/Object Abandon/Object
Lost/Running/Loitering/Parking/Crowd/Audio Abnormal Detection/Video Abnormal Detection |
| Alarm Trigger |
Motion Detection/IP Conflict/MAC Conflict/Port Alarm/Mask Alarm |
| Protocols |
IPv4/IPv6/HTTP/802.1x/FTP/SMTP/UPnP/SNMP/DNS/DDNS/NTP/RTSP/TCP/UDP/DHCP/PPPoE |
| User Permission |
4 Level/8 Users |
| Remote Connection |
5 Users Access at the Same Time |
| System Compatibility |
ONVIF (Profile S), SDK |
| Interface |
| Audio Input |
N/A |
| Audio Output |
N/A |
| Communication Interface |
1-ch RJ45 10M / 100M Ethernet Interface |
| Alarm Input |
N/A |
| Alarm Output |
N/A |
| Video Output |
N/A |
| On-board Storage |
MicroSD Card Slot, up to 128GB |
| Reset |
Y |
| General |
| Language |
English,Spanish,Korean,Italian,Turkish,Thai,Russian,Traditional Chinese,Simplified Chinese,Polish,French |
| Operating Conditions |
-35??60?(IR OFF) /-35??40?(IR ON), 0?95% RHG |
| Power Supply |
DC 12V±10%/PoE |
| Power Consumption |
Max. 5W(IR OFF) (ICR Instant Switch 8.5W) |
| Max. 7W(IR ON) |
| Circuit Protection |
TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V) |
| Impact Protection |
IP67 |
| IR Range |
25m |
| IR LEDs |
2pcs Array |
| Dimensions |
189mm×70mm×70mm |
| Weight |
0.7KG (IP Camera Only); 0.9KG (with Packing Box) |
