| Camera |
| Image Sensor |
1/3" CMOS |
| Core Processor |
ARM9 Architecture |
| Operating System |
Embedded Linux |
| Signal System |
PAL/NTSC |
| Min. Illumination |
Color: 0.05 Lux @(F1.4, AGC ON) |
| B/W: 0.01Lux @(F1.4, AGC ON); 0 Lux with IR |
| Shutter Time |
1s to 1/100,000s |
| Lens |
Motorized 2.8-12mm, Angle of View: 90.8°?32.1° |
| Lens Mount |
φ14 |
| Auto Iris |
DC Drive |
| Adjustment Range |
Pan:0° - 355°, Tilt: 0°- 75°, Rotation: 0° - 355° |
| Day& Night |
Dual IR Cut Filter with Auto Switch |
| WDR |
120 dB |
| DNR |
3D |
| Focus |
Auto |
| S/N Ratio |
>60dB |
| Compression Standard |
| Video Compression |
S+265/H.265/H.264H/H.264M/H.264B/MJPEG |
| Video Bit Rate |
32Kbps~16Mbps |
| Audio Compression |
G.711A/G.711U/ADPCM/AAC |
| Audio Bit Rate |
G711 8KHz, 64kbps |
| ADPCM 8KHz, 32kbps |
| AAC 48KHz, 96-320kbps |
| Image |
| Max. Image Resolution |
2560X1440 |
| Frame Rate |
PAL: 1440p@25fps, QXGA@25fps, 1080p@25fps, 960p@25fps,
720p@25fps, Up to 1280*720@50fps |
NTSC: 1440p@25fps, QXGA@30fps, 1080p@30fps, 960p@30fps,
720p@30fps, Up to 1280*720@60fps |
| Triple Stream |
Mainstream: 1440P(2560*1440) |
| Substream: D1(704*576) |
| 3rd stream: CIF(352*288) |
| Image Settings |
Brightness, Saturation, Contrast,Sharpness,Image Enhancement, Flip Mode |
| HLC |
Y |
| Smart Defog |
Y |
| Corridor Format |
Y, Available for 720P and Above |
| EIS |
Y |
| ROI |
4 Zones |
| Privacy Mask |
4 Zones |
| Picture Overlay |
200 × 200, BMP 24bit, Zone Configurable |
| OSD |
16×16, 32×32, 24×24, 48×48, 64×64, 96×96 Size |
| Letters Such as Week, Date, Time, Total 5 Regions |
| Network |
| Browser |
CHROME V45 or lower, IE, FIREFOX |
| Network Storage |
FTP |
| NTP |
Y |
| ANR |
Y |
| Video Analytics(VCA) |
Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost |
| /Running/Loitering/Parking/Crowd/Audio Abnormal Detection |
| /Video Abnormal Detection |
| Alarm Trigger |
Motion Detection/IP Conflict/MAC Conflict/Port Alarm/Mask Alarm |
| Protocols |
IPv4/IPv6/HTTP/802.1x/FTP/SMTP/UPnP/SNMP/DNS/DDNS |
| /NTP/RTSP/TCP/UDP/DHCP/PPPoE/HTTPS/ARP/RTP/QoS/MULITCAST/ICMP/IGMP |
| User Permission |
4 Level/8 Users |
| Remote Connection |
5 Users Access at the Same Time |
| System Compatibility |
ONVIF (Profile S), SDK,CGI |
| Interface |
| Audio Input |
1-ch, Bulit-in Mic |
| Audio Output |
1-ch |
| Communication Interface |
1-ch RJ45 10M / 100M Ethernet Interface |
| Alarm Input |
2-ch |
| Alarm Output |
1-ch |
| Video Output |
1Vp-p Composite Output(75Ω/BNC, for Internal Setup) |
| On-board Storage |
MicroSD Card Slot, up to 128GB |
| Reset Button |
Y |
| Extension |
1x USB |
| General |
| Language |
English,Spanish,Korean,Italian,Turkish,Thai,Russian, |
| Traditional Chinese,Simplified Chinese,Polish,French |
| Operating Conditions |
-35??60?(IR OFF) /-35??40?(IR ON), 0?95% RHG |
| Power Supply |
DC 12V±10%/AC24V±10%/PoE(802.3af) |
| Power Consumption |
Max. 5W(IR OFF) (ICR Instant Switch 11W) |
| Max. 7.5W(IR ON) |
| Circuit Protection |
TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V) |
| Impact Protection |
IP66, IK10 |
| IR Range |
20-30m |
| IR LEDs |
32pcs |
| Dimensions |
150mm×150mm×122mm |
| Weight |
1.0KG (IP Camera Only); 1.3KG (with Packing Box) |
| |
|
| S+265: |
Tiandy enhanced H.265 codec |
| ANR: |
Auto store video in SD card when NVR disconnected, and upload video to |
| |
NVR when resumed connection(Only Support Tiandy ANR NVR) |
