| Вход адио/ видео |
| IP видео входы |
5 каналов |
| Аудио вход |
N/A |
| Сеть |
| Incoming Bandwidth |
40Mbps |
| Outgoing Bandwidth |
40Mbps |
| Remote Connection |
16 Users,Up to 48ch Videos |
| Browser |
IE8,IE9,IE10,IE11,Firefox24 |
| Mobile Software |
P2P&DDNS for IOS&Android (Tiandy: Easylive, Neutral: Mobilelive) |
| Internet Protocol |
TCP/UDP/HTTP/MULTICAST/UPnP/DHCP/PPPoE/DDNS/NFS/FTP/NTP/HTTPS/RTSP/SMTP/HTTPS/SADP |
| Email |
Activated by Alarm |
| ANR |
Y, Auto download video from camera SD card, Which was stored when disconnnection (Only Support Tiandy ANR IP Camera) |
| Advanced |
Remaining Bandwidth Display |
| Video/Audio Output |
| HDMI Output |
1-ch Resolution: 3840×2160,2560×1600, 2560×1440?1920×1080?1280×720?
800×600,1024×768,1366×768,1440×900,1280×800 |
| VGA Output |
1-ch Resolution: 1920×1080?1280×720?800×600,1024×768?1366×768,1440×900,1280×800 Adjustable Output mode, Self-adaptive Resolution |
| Frame Rate |
Mainstream 25fps(P)/30fps(N) Substream 25fps(P)/30fps(N) |
| I-Frame Record |
Y |
| Recording Resolution |
4K(3840*2160,3264*2448,3296*2472)/6MP(2752*2208,3008*2008,2408*2008)/5MP(2560*1920,2592*1944,2592*1920,2528*2128/4MP(2560*1440,2592*1520)/3MP(2048*1536)/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Audio Output |
N/A |
| Synchronous Playback |
1-ch 4K/6MP/5MP/4MP/2-ch 3MP/4-ch 1080P/720P/4CIF Synchronous Playback |
| Decoding |
| Live View/Playback |
4K(3840*2160,3264*2448,3296*2472)/6MP(2752*2208,3008*2008,2408*2008)/5MP(2560*1920,2592*1944,2592*1920,2528*2128/4MP(2560*1440,2592*1520)/3MP(2048*1536)/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability |
1-ch 4K/6MP/5MP/4MP/2-ch 3MP/4-ch 1080P/5-ch 720P/4CIF |
| Display Split |
1/4/6 |
| E-Zoom |
Y |
| Hard Disk |
| SATA |
1 SATA for 1HDD |
| E-SATA |
N/A |
| Capacity |
Up to 4TB |
| NTFS Files System |
Y |
| HDD Management |
Group and Quota, Customized Recording Days |
| External Interface |
| Network Interface |
1X RJ-45 10/100Mbps Self-adaptive Ethernet Interfaces |
| Serial Interface |
N/A |
| USB Interface |
1x USB3.0, 1x USB2.0 |
| Alarm In/Out |
0/1 |
| Advance |
| NAS |
NFS Protocol, Support Manual Backup Only |
| Plug and Play |
Y, Only for Tiandy Cameras |
| Image Flip |
Y, Only for Tiandy Cameras |
| Hot Standby |
N+M |
| Corridor Mode |
Y, 16:9 to 9:16, Only for Tiandy Cameras |
| Video Analytics(VCA) |
Support 5-ch Camera VCA Function,Including Tripwire/Double Tripwire/Perimeter/Object Abandon/Object Lost/Running/Loitering/Parking/Early Warning/Crowd/Face Detection/People Counting/Audio Abnormal Detection/Video Abnormal Detection/On duty Detection |
| Smart Search |
Quickly Search Target Videos according to Channel No., Records Type, Records Time, File Type and VCA( Only for Tiandy Cameras ) |
| Trigger Recording |
Manual/Timing/Motion Detection/Port Alarm/ VCA Alarm/Video Occlusion |
| Smart Recording |
Set Recording Bite Rate for Different Time |
| Alarm Recording |
Pre Alarm Default 10s (5/10/15/60s Optional) , Post Alarm Default 10s (10/15/30/60/600s Optional ). |
| One Key Control |
Intercom, Recording |
| Records Format |
SDV, Export MP4 in H.264 Format |
| Records Encryption |
Да |
| Records Tag |
Да |
| Onvif |
Onvif(Profile S) |
| Физические характеристики |
| Язык меню |
English, Spanish, Korean, Italian,Turkish,Thai, Russian, Traditional Chinese,Simplified Chinese, French, Polish |
| Питание |
DC12В 2A |
| Потребляемая мощность (без HDD) |
≤ 10 Вт |
| Рабочая температура |
-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Относительная влажность |
10 % ~ 90 % |
| Высота |
1U |
| Габариты |
44mm×255mm×231mm |
| Вес |
0.8KG (without HDD), 1.4KG (with Packing Box) |
